Input sensitivity

2.1 mV/Pa

RF Frequency range

584-608 MHz/823-832 MHz & 863-865 MHz

Modulation

Frequency Modulation

Maximum channel number

96 for USA frequency band & 18 for EU frequency band

Polar pattern

Cardiod

External power adaptor (use only the supplied adapter)

DC 12 V/600 mA

THD

<1% to 1 kHz

Transmission power

14 mW

Operation time

>8 hours (1300 mAh)

Capsule

Dynamic

Output

XLR balanced, TS unbalanced

Sensitivity

<-94 dBm

S/N ratio

>80 dB(A)

Dimensions (W x H x D)

202 x 147 x 43 mm (7.9 x 5.8 x 1.7")

Weight

371 g (0.82 lbs)

Dimensions (L x Diameter)

265 x 55 mm (10.4 x 2.16")

Modulation

Frequency modulation

Internal batteries

2 x 1.5 V DC (AA)

Power consumption

≤120 mA

Weight

226 g (0.5 lbs)

Power switch

On/off
