| Mic Channel Controls: | • 6 Mono Mic/Line Channels (XLR, ¼” Jack – Balanced) • Mic Input Impedance: 3kΩ • Line Input Impedance: 47kΩ • -20dB Attenuation Switch • Gain potentiometer • Individual Low (80Hz), Mid (2.5KHz) & Hi (15KHz) EQ potentiometers (-15/+15 dB) • Effects Send Potentiometer • Monitor Potentiometer • Pan Potentiometer • Level Fader,60mm |
| Master Controls: | • 16 Digital Effect Processor • Effect Repeat Potentiometer • Effect Send Level Potentiometer • Effects Level Fader, 60mm • Monitor Send Potentiometer • 2TK Play / MP3-USB Level Potentiometer, Switchable • MP3-USB / SD Card Media player & Bluetooth module, LCD Screen (Play, Pause, Folder select, >>,<<) • Headphones Potentiometer • 48V Phantom switchable Channels 1-3 & Channels 4-6 • Individual Left & Right Master Level Faders, 60mm • Mix Out Fader, 60mm • 12 Bar LED Master Level /Mix Out- Monitor Indicators, switchable • 7 Band Graphic Equaliser, +/- 12dB (100, 250, 500, 1K, 2K, 4K, 8K – Hz) |
| General: | • Balanced XLR Outputs (Left & Right) • Unbalanced ¼” Jack Line Outputs (Left & Right) • RCA Record Output (Left & Right) 10kΩ • Monitor Unbalanced Output ¼” Jack, 600kΩ • Mix Unbalanced Output ¼” Jack, 600Ω • Effect Unbalanced Send ¼” Jack, 600Ω • 2TK Play – Unbalanced RCA (Left & Right) 10kΩ • THD: 20-20KHz, <0.1% • Noise: -120dB @ Max Gain • Frequency Response: 20-20KHz (+/- 2dB) • Inbuilt PSU, IEC Mains Connection • Dimensions: 415mm (Width) 360mm (Depth) 105mm (Height) • Weight: 3.75Kg |
