Roxtone RX3FD - 3 pole XLR female Chassis Mount

Description

• Upgrade your custom audio panels, stage boxes, and wall plates with the high-performance RX3FD-NT 3-Pin Female XLR Chassis Mount Connector.
• Part of the premium Leader Series, this panel-mount component is engineered to provide professional-grade signal routing, exceptional structural durability, and lasting performance for pro-audio installations, recording studios, and touring sound racks.
• The socket is integrated into a unified D-series size layout, which serves as the global standard for audio panel cutouts.
• Built with a heavy-duty, die-cast Zinc alloy housing and finished with top-tier nickel plating, it delivers superior shielding properties against disruptive radio frequency (RF) and electromagnetic interference (EMI).
• Inside the shell, the connector features high-grade bronze contacts paired with selective tin plating, guaranteeing low contact resistance, excellent signal transfer, and effortless solderability during panel integration.
• This chassis receptacle is outfitted with a sturdy, spring-loaded metal latch lock mechanism that ensures your connected male XLR cables remain firmly locked in place, avoiding accidental disconnects from heavy pulling or stage vibrations.
• With clean solder cups designed to hold wire safely and standard countersunk mounting holes, this Leader Series panel connector is the choice for constructing robust, tour-grade balanced audio distribution systems.

Features

• Standard D-Series Footprint: Uses a globally recognized layout sizing for seamless compatibility with pre-cut stage boxes, patch bays, and wall plates.
• Heavy-Duty Nickel Shell: Die-cast Zinc alloy outer housing offers rigid physical protection and excellent structural integrity.
• Reliable Tin-Plated Contacts: Bronze contact tubes feature specialized plating to offer highly efficient electrical conductivity and smooth solder tracking.
• Secure Spring Latch Lock: Integrated metal push-button latch system prevents accidental cable dropouts during intensive live performances.
• Optimized Solder Cups: Features large, easy-access rear solder terminals to accelerate wiring workflows and ensure stable connections.
• Professional Noise Shielding: Full-metal construction safely grounds out stray static, buzzing, and electromagnetic interference.

SpecIfications

• Model Code: RX3FD-NT
• Product Series: Leader Series
• Connector Type: XLR Female (Chassis / Panel Mount)
• Number of Pins (Poles): 3-Pin
• Mounting Shape: Standard D-Shape Flange
• Shell Material: Die-cast Zinc Alloy
• Shell Plating: Nickel
• Contact Material: Bronze
• Contact Plating: Tin
• Inner Insulation Core: PA66 30% Glass Fiber Reinforced (GR)
• Locking Mechanism: Spring-Loaded Latch Lock (Push Release)
• Termination Method: Rear Solder Terminals
