TOURUS+ ACTIVE SERIES
Features
- Dual 35 mm pole sockets
- 5 x M8 rigging points
- Optional U brackets and soft covers
- Bluetooth connectivity
- TWS functionality
- Mic / Line inputs for both channels
- Balanced Link outputs
- 4 presets with FIR filters
TOURUS+A10
Key Features
- 10″ Active loudspeaker
- Max SPL @ 1 M : 125 dB
- 2.5″ LF Voice coil
- 320 W Continuous
- 640 W Peak
Let's look inside
All Tourus+ models are equipped with dual 35 mm pole sockets. 0° and 3°
This is really useful for targeting your audio…..at your audience.
Versatile
The polypropylene cabinet of all TOURUS+ models has been designed with a 45° monitor angle.
TOURUS+ easily works not only as a front of house loudspeaker but as a floor monitor too!
Cover IT up
With soft internal padding these optional ‘soft cover’ accessories are ideal for simple transportation or as a dust cover when the TOURUS+ is not being used.
The TOURUS+ carry handles are easily accessible even when it is inside its TOURUS+ Soft cover.
Control
Around the back is the main screen and control. All the options are accessible to tweak the TOURUS+A to sound great in your environment.
Specifications
| Model Name | TOURUS+ A10 |
|---|---|
| System Type | 10″ Active |
| Configuration | two-way bi-amped |
| Frequency Response (+/-3 dB) | 63 Hz – 20 KHz |
| Frequency Range (- 10 dB) | 55 Hz – 20 KHz |
| Calculated Maximum SPL @1 m | 125 dB |
| Low Frequency Transducer | |
| Size | 10” |
| Voice Coil Size (inches) | 2.5″ |
| High Frequency Transducer | |
| HF Driver Type | Compression Driver |
| Voice Coil Size (mm / inches) | 1.33″ |
| Exit Size (mm / inches) | 1.37″ |
| Diaphragm Material | Titanium |
| Waveguide Type | Constant Directivity |
| Nominal Coverage (H x V) | 90° x 60° |
| Special Features | Bluetooth, Display, FIR, editable 3 band EQ |
| Preset | NORMAL, LIVE, DJ, SPEECH |
| Location mode | Stand or Monitor |
| Driver brand | Wharfedale Pro |
| Amplifier Design | Class D |
| Power Rating: | 640 W Peak (560 W LF +80 W HF), |
| 320 W Continuous (280 W LF + 40 W HF) | |
| Thermal Protection | Amplifier Shut Down. Auto Reset |
| Low Line Voltage Shut Down | 60% Nominal Line Voltage |
| Driver Protection | Independent LF/ HF RMS and Peak Limiters |
| DC and Short Protection | Yes |
| Clip Limiter | Yes |
| Limiter Indicator | Red LED |
| Signal Indicator | Green LED |
| Power/Active Indicator | White LED |
| Find Function Indicator | Blue LED |
| Input Sensitivity | +4 dBu |
| Maximum Input Level | +18 dBu |
| Input Impedance | Balanced:10 KΩ |
| AC Power details – Power Supply | 220~240 V AC / 100~120 V AC 50/60 Hz |
| Input | Balanced socket XLR |
| Link | Balanced pin XLR |
| AC Power | AC Input: VDE |
| Rigging & Hardware: | 5 x M8 |
| Optional Accessories | WPB-T+10 |
| Heavy-duty soft cover | |
| Handle | 1 on top, 1 on side |
| Pole Mount | Dual Angle (0°/-3°) 35 mm |
| Cabinet Type | Trapezoid |
| Enclosure Material and finish | Polypropylene |
| Colour Options | Black paint |
| Grille Material & Finish | Powder coated steel |
| Monitor Angle | 45° |
| Dimensions – Unpacked (mm / inches): | |
| Height | 527.9 mm |
| Width Front | 320 mm |
| Width Rear | 178.9 mm |
| Depth | 299.5 mm |
| Dimensions – Packed (mm / inches): | |
| Height | 582mm |
| Width Front | 367.0 mm |
| Width Rear | |
| Depth | 342.0 mm |
| Weight | |
| Net Weight | 12.6 Kg |
| Gross Weight | 14.8 Kg |
