| Mic Channel Controls: | •8 Mono Mic/Line Channels (XLR, ¼” Jack – Balanced) • Mic Input Impedance: 2kΩ • Line Input Impedance: 47kΩ • Low Cut Switch • Gain potentiometer • Compressor potentiometer, Channels 1-4 • Individual Low, Mid & Hi EQ potentiometers (-15/+15 dB) • Effects Send Potentiometer • Aux Potentiometer • Pan Potentiometer • Level Potentiometer |
| Master Controls: | • 16 DSP Effects processor • Effect Repeat Potentiometer • Effect Level Potentiometer • Aux Send Potentiometer • Aux Return Potentiometer • 2TK Play / MP3-USB Level Potentiometer, Switchable • MP3-USB Media player/recorder with LCD Screen (Play, Pause, Record, Folder select, >>,<<) • Headphones / Control Room Potentiometer • 48V Phantom Power switch • Master Level Fader, 60mm • 8 Bar LED Master Level Indicators |
|
Stereo Line / Mono Mic Channel Controls: |
• 2 Stereo Line Channels (Unbalanced, ¼” Jack, Left & Right) • Input Impedance: 10KΩ • -10dB Attenuation Switch • Individual Low, Mid & Hi EQ potentiometers (-15/+15 dB) • Aux Potentiometer • Balance Potentiometer • Level Potentiometer |
| General: | • Unblanced ¼” Jack Outputs (Left & Right) 75Ω • Unbalanced ¼” Jack Control Room Outputs (Left & Right) 75Ω • RCA Record Output (Left & Right) 1kΩ • Stereo Unbalanced Aux Return ¼” Jack (Left & Right) 10kΩ • Aux Send ¼” Jack, 75Ω • 2TK Play – Unbalanced RCA (Left & Right) 10kΩ • Separate PSU adaptor • Dimensions: 380mm (Width) 275mm (Depth) 60mm (Height) • Weight: 2.5Kg |
