RCF ART 710A MK4

RCF ART 710A MK4

R 11,900.00 R 13,000.00 Save R 1,100

Tax included

Only 6 left!

In store 3abefc92 23cc 47b2 a5ac 6821759c6c25

ACTIVE TWO-WAY SPEAKER

  • 1400 WATT 2-way peak power
  • 129 dB Max SPL
  • 1" Compression Driver, 1.75" v.c.
  • FiRPHASE Technology
FEATURES
  • 129 dB Max SPL
  • 1400 WATT 2-way peak power
  • Innovative DSP Processing
  • 1" Compression Driver, 1.75" v.c.
  • 10" Woofer
  • 90°x70°, wide dispersion constant directivity horn
  • FiRPHASE Technology

ART 710-A MK4 is a unique product in its category. The compression driver with custom designed dome and high power voice coil offers unique vocal clarity and sound projection. The 10” woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.

New perspective on linearity
RCF speakers are designed using a proprietary and advanced digital FiR technology, conceived to deliver transparent sound, absolute clarity, and perfect imaging to the listener.
The special FiRPHASE filters allow for coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies in the system.

Responsive Image
Responsive Image
Superior transducers
Woofers and compression drivers are precision built taking advantage of RCF’s technologies and a wealth of professional knowledge and experience dedicated to achieving extremely high standards.

Powerful class D amplifiers
RCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 7 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminum structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the ART 7 amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.
Responsive Image

Bring ART with you

The RCF ART 7 Series has earned the prestigious international Red Dot Design Award in the Product Design category. Receiving the renowned Red Dot acts as proof of the excellent design achievements of professionals and up-and-coming talent alike, thus symbolising a seal of quality.
Responsive Image
SPECIFICATIONS
SPECIFICATIONS
ACOUSTICAL SPECIFICATIONS
Frequency Response
50 Hz ÷ 20000 Hz
Max SPL @ 1m
129 dB
Horizontal coverage angle
90°
Vertical coverage angle
70°
TRANSDUCERS
Compression Driver
1 x 1.0'', 1.75'' v.c
Woofer
1 x 10'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input signal
bal/unbal
Input connectors
XLR, Jack
Output connectors
XLR
Input sensitivity
-2 dBu/+4 dBu
Mic. Input Sensitivity
-32 dBu
PROCESSOR SECTION
Crossover Frequencies
1600 Hz
Protections
Thermal, RMS
Limiter
Soft Limiter
Controls
Volume, Boost, Mic/Line
POWER SECTION
Total Power
1400 W Peak, 700 W RMS
High frequencies
400 W Peak, 200 W RMS
Low frequencies
1000 W Peak, 500 W RMS
Cooling
Convection
Connections
VDE
STANDARD COMPLIANCE
Safety agency
CE compliant
PHYSICAL SPECIFICATIONS
Hardware
2 x M10
Handles
1 Top
Color
Black
SIZE
Height
548 mm / 21.57 inches
Width
340 mm / 13.39 inches
Depth
305 mm / 12.01 inches
Weight
14.2 kg / 31.31 lbs
SHIPPING INFORMATION
Package Height
585 mm / 23.03 inches
Package Width
425 mm / 16.73 inches
Package Depth
405 mm / 15.94 inches
Package Weight
16.8 kg / 37.04 lbs
